4G LTE Vehicle GNSS Tracker – IP67 Waterproof Remotely Oil Cut/Resume

The MV901G is a 4G+2G dual‑network tracker with IP67 waterproof rating. Its compact body fits diverse installation spots. It supports remote fuel cut/resume, ACC detection and multiple security alarms. Multi‑satellite positioning plus 140mAh backup battery delivers stable tracking under 9‑95V wide voltage.

Product Features

Remote Cut-off Fuel/Power

Remotely cut fuel or power for anti-theft protection and emergency safety control.
ACC Status Detection

Capture vehicle ACC status for accurate activity records and asset supervision.
Ignition On‑Off Alarm

Receive instant alerts when your vehicle ignition turns on or off. Catch unauthorized activity and safeguard your car against theft.
IP67 Waterproof

Withstand temporary immersion, adapt to harsh outdoor environments.
History Route Playback

Replay 180 days route to trace asset paths and secure your assets.
Geo-fence

Get alerts for unauthorized zone crossings, restrict vehicle activity range.
Real-time Tracking

Monitor your asset location live, keep full control all the time.
Movement Alarm

Get alerted the moment your vehicle moves, perfect for parking security.
Vibration Alarm

Trigger alerts on abnormal vibration, prevent vehicle tampering.
Overspeed Alarm

Trigger alerts when speed exceeds limit, manage reckless driving risks.
Low Voltage Alarm

Monitor car battery voltage, alert you early to avoid vehicle breakdown.
GNSS+LBS Positioning

Precise satellite positioning, LBS backup when satellite signals drop.

Product Specifications
Key Features
Download (Manual /Catalog)

Filter

Device Param

Model	MV901G
Demension	90.6mm(L)34mm(W)20mm(H)
Weight	68g
Working Voltage	DC 9V - 95V
Working Temperature	-20℃ - 75℃
Working Humidity	10%-85%RH
Built-in Memory	3000pcs GPS data can be stored at network blind area

GNSS

Hot/Cold Start	<1s，<32s @ Open Sky
GPS Channels	32
GNSS Antenna	Built-in Ceramics GNSS Antenna, 25mm25mm4mm
Positioning Type	GPS+GLONASS+LBS+AGPS
GPS Frequency	L1: 1575.42±1.023MHz
BDS Frequency	B1:1561.098±2.046MHz
Accurancy	Location accuracy: <1.5mCEP
	Location accuracy: <10m（1σ）
	Timing accuracy: <30ns（1σ）
	Speed accuracy: <0.1m/s（1σ）

Cellular

Technology	2G GSM+4G LTE CAT1
Working Frequency	MV901G-SA Module: SIMCOM A7670SA GSM: 850/900/1800/1900MHz LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28/B66
Working Frequency	MV901G-EU Module: SIMCOM A7670E GSM: 900/1800MHz LTE-FDD: B1/B3/B5/B7/B8/B20
Cellular Antenna	Built-in, FPC

Power

Battery	Built-in 3.7V 140mAh Polymer Battery
Work Current	12V/Average 40mA
Sleep Current	12V/Average 10mA

Interface

Digital Input	1 x digital input for ignition detection
Digital Output	1 x digital output for cut off oil
SIM Card	Normal SIM Card
Firmware Upgrade	OTA & UART Serial Upgrade
LED indication	GSM LED
	Charging LED
	GPS LED
