0.3MP Photo Capture Camera for GPS Tracking Device, Manual & Alarm Trigger Snapshot
This 0.3MP camera is an accessory for vehicle GPS trackers. It supports photo snapshot only, no video recording. It can take photos manually or auto capture images when alarm triggers. Upload photos through GPS tracker for remote fleet scene verification, simple wiring for vehicle installation.
Product Features
-
Budget‑friendly Visual UpgradeCost‑effective 0.3MP solution to add snapshot function to GPS trackers. -
Dual‑mode SnapshotManual snapshot available; auto‑capture photos upon alarm activation. -
Satisfactory Scene ClarityProvides sharp enough images to observe vehicle interior and status. -
Easy InstallationLightweight compact body with simple wiring for in‑vehicle mounting.
- Product Specifications
Filter
Sensor Parameter
|
Image Sensor
|
1/4" CMOS, OV7725
|
|
Effective Pixels
|
0.3MP
|
|
Photosensitive Area
|
3984μm × 2952μm
|
|
Gray Scale
|
10 Levels
|
|
Gamma Coefficient
|
0.45
|
|
Signal-to-Noise Ratio
|
>48 dB
|
Image Performance
| Minimum Illumination | 0.8 Lux / F2.0（0 Lux with IR ON） |
| AGC | Auto |
| White Balance | Auto |
| Backlight Compensation | Auto |
| Image Output Format | JPEG |
Communication
| Interface | RS232（RS485 Optional） |
| Baud Rate | 9600 / 38400 / 57600 / 115200 bps optional |
Lens & Optics
| Lens | 2.8mm, F=2.0（Optional） |
| Field of View | 90° |
Electrical
| Working Current | 90mA ±10% |
| Power Supply | DC 5V ±10% |
Product Parameter
| Cable | 5m, 4-core wire |
| Application Fields | Image acquisition systems, environmental monitoring, industrial process control, medical equipment, video phones, security & anti-theft, vehicle GPS, image capture systems |
| Application GPS Tracker | MiCODUS MV501G |
