| PHYSICAL SPECIFICATION | |
|---|---|
| Dimensions | 73 x 26 x 13mm (L x W x H) |
| Weight | 27g |
| MODULE | |
|---|---|
| Name | |
| Technology | |
| Working Specifications | |
|---|---|
| Network | GSM/GPRS |
| Bands | 850/900/1800/1900Mhz |
| Chip | MT2503D |
| GPS sensitivity | -161dBm |
| GPS Position accuracy | 5m(In 3D positioning mode) |
| First positioning time | Cold start 45-120s Warm start 35s Hot start 1s |
| Working Voltage | 8-95V |
| Storage temperature | -40°C to +85°C |
| Working temperature | -20°C to +70°C |
| Humidity | 5%--95% Not solidified |
